Android-x86 on SD card with NTFS, Secure Boot and UEFI

I will show you how to install the 64-bit version of Android-x86 7.1rc2 (and likely other versions such as CM14.1 rc1, or other operating systems based on Android-x86 such as RemixOS), on a SD/microSD card using NTFS as the filesystem (thus providing a fast Android experience) with Secure Boot and UEFI boot.



Most of the tutorials available on the web show how to install Android-x86 on a USB storage device. Even though I was able to find some information about how to install on a microSD card reader, I found no information whatsoever about doing so together with:

  • Using NTFS (without giving up Secure Boot) – for performance reasons;
  • What to do when the microSD card can be booted but Android-x86 never gets “detected”.

Using NTFS as the filesystem for storing Android-x86’s virtual partitions was a priority for me, since I originally tested Android-x86 on a cheap USB stick and observed that the performance/latency difference of EXT4 or FAT32 vs. NTFS was jaw-dropping, with the EXT4 or FAT32 being almost unusable.

I mentioned not giving up Secure Boot when using NTFS. Well, I would eventually have made the effort to give up Secure Boot in order to use Android-x86 with NTFS. However, I simply was not successful in booting to GRUB when using the card, but was successful when using the USD drive. Using the card simply printed the following and froze:

tGRUB Loading stage1.5.



So, to summarize, this post will allow you to:

  • Install Android-x86 on a SD/microSD card (via a built-in reader);
  • Work-around Android-x86’s rejection of some card readers;
  • UEFI-boot into the Android-x86 installation
  • Keep Secure Boot enabled
  • Use NTFS as the filesystem for the Android virtual partitions, for high performance
  • Use either a GPT or a MS-DOS partition table
  • Keep using part of your SD card as a removable storage on Windows/Linux



And here are some quick links to the multiple sections:



Before moving on, make sure that:

  • Your computer includes a SD/microSD card reader;
  • Your computer can UEFI-boot from said reader;
  • You have access to parted or GParted (you can use an Ubuntu live image or the specialized Parted Magic live image for this);

The computer I have used for my installation was the Dell Latitude 7480, and from what I can gather any Dell E7x40, E7x50, E7x60, E7x70, 7x80 should work the same way, if not many others from Dell. I can’t guarantee that this post will work with your computer even if the above 2 points tick, since it will depend on the manufacturer of the card reader, as well as whether Linux kernel modules are available for it in Android-x86.

I will mention keyboard shortcuts, terminology, screens and show photographs from the Dell Latitude 7480. If you are using a different laptop, you’ll need to find the equivalent items. I will also mention microSD specifically from now on, since that’s the card type this laptop can read.



System configuration

Get to the BIOS setup tool of the computer (press F2 during the POST screen – right after turning on the computer) and:

  • Make sure Legacy boot is disabled: Go to General, Advanced Boot Options and uncheck Enable Legacy Option ROMs;
  • Make sure Secure Boot is enabled: Go to Secure Boot, Secure Boot Enabled, and check Enabled;
  • Make sure SD card boot is enabled: Go to System Configuration, Miscellaneous Devices and check Secure Digital (SD) Card Boot.



Prepare your devices

You will need 2 or 3 devices:

  • Flash Android-x86 7.1rc2 64bit to a USB drive(will be the installer) – you can use https://sourceforge.net/projects/win32diskimager/ for this;
  • Grab a microSD card with at least 8GB of capacity (will be the destination of the installation)
  • Optionally flash a live image to another USB drive, or use a live CD/DVD that provides the parted, GParted or equivalent tools for partitioning the microSD card – if you already have Linux on your computer you can simply use it.

The microSD card needs to have either a GPT or a MS-DOS partition table (I have used and tested MS-DOS, but GPT should work as well).

Then make sure the card has the following partitions in the following order:

  • (optional) NTFS/FAT32/exFAT partition to be read by both Android and Windows/Linux – whatever capacity makes sense to you. It is VERY IMPORTANT that this partition be the first partition on the list, otherwise Windows will not be able to see it (Linux will still do the job). You must also set the boot flag, which will tell Windows that this is the "active" partition.;
  • Tiny FAT16 partition (anything above 20 MB should be safe) – set the following flag: efs (VERY IMPORTANT, otherwise you won't be able to boot the SD card);
  • All the remaining space should be converted to an NTFS partition with at least 4GB (the less you have here, the quicker Android will run out-of-space and become unstable… 4GB is extremely little in case you intend to install some of the most popular apps, to illustrate).



Install Android-x86

Turn the computer on again, with the Android-x86 installer USB drive plugged-in, and press the F10 key to launch the one-time boot menu. Choose the USB device.

The Android-x86 GRUB menu will show up, choose the third option:


When you are faced with the list of devices/partitions where you can install Android-x86, you might notice that the partitions of your microSD card are missing (they are in the Dell Latitude 7480). This depends on the manufacturer of the microSD card reader but my expectation is that they will be missing more often than not. In order to make the partitions show up on the list, the correct kernel module for the card reader needs to be loaded. For the Dell Latitude 7480 the module name is rtsx_pci_sdmmc, but it may be different in other computers. One way to find the name of the module is to launch another Linux-based OS such as Ubuntu or Parted Magic and running the following commands to inspect their output and obtain the name of the module:

$ lsmod | grep –i sd
$ lsmod | grep –i mmc
$ lspci –kv | grep –i card

Or by finding out the module driving /dev/mmcblk0p1, for example. You can check here for more information at [1]

Once you know the module name, in my case rtsx_pci_sdmmc, just boot the Android-x86 usb drive again and, once on the list of partitions, press Ctrl+Alt+F2 to switch to tty2 and run the following command (modify accordingly):

$ modprobe rtsx_pci_sdmmc

Then press Ctrl+Alt+F1 to go back to tty1 (where the list of partitions is), and select “Detect devices”. Hopefully, the 2/3 partitions of your microSD card will now show up and will probably be called mmcblk0p1 and mmcblk0p2 and mmcblk0p3. The numbers will reflect the order of the partitions you created earlier (first to last), and the filesystem type will also give you another indication as to which partition is which.

Choose the microSD card NTFS partition as the destination of the Android-x86 installation.



When asked if you want to install EFI GRUB, say yes.

When asked if you want to make the /system partition read+write, say yes.

When asked how big you want the /data partition to be, make it about 1500MB if you chose to have a 4GB NTFS partition. For every additional GB your NTFS partition has, add an additional 1024MB to the /data partition size. I am using an NTFS partition with 23GB and my /data has a capacity of 20GB. If the microSD card isn’t very fast, you might want to try with only 600MB to make it quicker just so you can check if Android-x86 works in the end (and then repeat the installation with more space for /data).



Then wait from a few minutes to more than an hour, depending on the /data size and the microSD card speed.

When finished, select Reboot. However, Android-x86 won’t work out-of-the-box after rebooting.



Making it boot

At this point, Android-x86 is already installed on the microSD card. However, the USB installation drive/media will be used one more time in the next section, so keep it around.

To make Android boot there are 2 important issues that need to be corrected (might be only 1 in some cases):

  • Just like rtsx_pci_sdmmc (or another module) was missing during installation, so will it when Android-x86 attempts to boot (the initial ramdisk that GRUB loads, which is then supposed to load the rest of operating system, will not include the microSD card reader kernel module by default, and so will simply fail by getting stuck in Detecting Android-x86…………………………
  • Additionally, the initial ramdisk (initrd.img) and related files (kernel and ramdisk.img) will be present in the NTFS partition but GRUB will not be able to read from the NTFS partition because 1) GRUB was not installed with the NTFS GRUB module and 2) even if it was (or if manually installed), Secure Boot will prevent GRUB from reading non-FAT partitions. So, with Secure Boot disabled, one could copy the ntfs.mod from another GRUB and then issue insmod ntfs and set root=’(hd0,3)’ assuming the card reader is hd0, before the existing GRUB commands for the Android-x86 boot entry, and it would work (but again, Secure Boot needs to be disabled).

At this point, go back to your Linux installation or Linux live image.

There, 3 things have to be done with regards to the partitions and files from Android-x86:

  • Extract the Android-x86 squashfs image in order to search and copy necessary kernel modules;
  • Copy missing kernel modules to the initrd image;
  • Copy new initrd image, kernel and ramdisk files to the FAT16 partition instead of the NTFS partition.

The next section will go through all of this.



Get the necessary kernel modules

To get the necessary kernel modules for booting Android-x86 (only rtsx_pci_sdmmc and its dependency rtsx_pci in my scenario – you should look for the dependencies of the modules you need using the lsmod command). The Android-x86 live squashfs image should first be extracted so that you can access its files. So plug in the live USB drive and mount it in your Linux system. Then follow the following steps:

$ cd && mkdir sfs # create a directory locally to store the squashfs contents
$ cp /path/to/android_x86_live/system.sfs ~ # copy the system.sfs squashfs file
$ cd && unsquashfs system.sfs # extract the image from it
$ mount -t ext4 system.img sfs # mount it to the directory we created earlier
$ cd ~/sfs/lib/modules/4.9.54-android-x86_64-gfb63269e5ada/kernel # change kernel version here accordingly, if not using 7.1rc2
$ find . -name *rtsx* # find the path to the missing module (and similarly named ones)
./drivers/memstick/host/rtsx_pci_ms.ko
./drivers/memstick/host/rtsx_usb_ms.ko
./drivers/mfd/rtsx_pci.ko               # yep, I need this one
./drivers/mfd/rtsx_usb.ko
./drivers/mmc/host/rtsx_pci_sdmmc.ko    # yep, I need this one
./drivers/mmc/host/rtsx_usb_sdmmc.ko

You now know where the needed modules are, so let’s temporarily switch to something else: getting the original initrd image in order to later update it with the additional modules.

$ cd && mkdir initrd # create a directory locally to store the initrd contents
$ cp /path/to/android_ntfs_partition/android-7.1-rc2/initrd.img initrd/ # copy the initrd file
$ cd initrd && mv initrd.img initrd.gz
$ gunzip initrd.gz
$ cpio -id < initrd # extract the cpio-archived initrd image
$ rm initrd

The initrd image is now extracted, so you can modify it as needed. In terms of the microSD card reader kernel module, the 2 modules above will be copied to initrd and will be loaded by changing one of the scripts (the same one that issues the Detecting Android-x86 message).

$ cd ~/sfs/lib/modules/4.9.54-android-x86_64-gfb63269e5ada/kernel
$ cp ./drivers/mfd/rtsx_pci.ko ~/initrd/lib/modules/
$ cp ./drivers/mmc/host/rtsx_pci_sdmmc.ko ~/initrd/lib/modules/
$ vim ~/initrd/init # use any editor you feel comfortable to edit this file

Inside the init file, look for the following:

echo -n Detecting Android-x86…

Before that (should be around line 135), add the following:

echo "Loading SD card reader modules (rtsx_pci, rtsx_pci_sdmmc)… (credit: igordc.com)"
busybox insmod /lib/modules/rtsx_pci.ko
busybox insmod /lib/modules/rtsx_pci_sdmmc.ko
sleep 2

What these lines do is to simply load the modules manually, from where we copied them to (although from the perspective of the initial ramdisk already running, so don’t doubt that the paths are correct in the lines above).

Change the message in the “echo” line however you want, or remove it.



Now that the initrd image is finally ready, it’s time to turn it back into a single file.

$ cd ~/initrd
$ find . | cpio -o -H newc | gzip > ../initrd.img

And copy that file, along with the ramdisk and kernel files that are in the NTFS partition, into the FAT16 partition. This will make GRUB find the files even if Secure Boot is disabled or the NTFS GRUB module is not present.

$ mkdir /path/to/android_fat16_partition/android-7.1-rc2
$ cp ~/initrd.img /path/to/android_fat16_partition/android-7.1-rc2/
$ cp /path/to/android_ntfs_partition/android-7.1-rc2/ramdisk /path/to/android_fat16_partition/android-7.1-rc2/ramdisk
$ cp /path/to/android_ntfs_partition/android-7.1-rc2/kernel /path/to/android_fat16_partition/android-7.1-rc2/kernel



Happy booting

With a fixed initrd.img together with a new location for it and its relatives, GRUB should now be able to boot the initial ramdisk  which should be able to automatically detected Android-x86 on the microSD card, since any missing kernel modules will now be loaded.



Links:

Jan 3, 2016 - Windows 10 Search - These results may be incomplete

Comments

Ever since my laptop was updated from Windows 8.1 to Windows 10 through Windows Update, the search feature has been behaving very poorly due to some past damage buried deep in Windows, its registry or somewhere within/around the Indexing service. This post is not about discussing what might be causing all these issues, but to provide a workaround which might work for some instances of two specific symptoms: missing searched items in the start menu, including items from the Control Panel, and a constant warning claiming that "These results may be incomplete..." as can be seen in the partial screenshot below.


At the end of the post I provide links to discussions and suggestions I found about the same symptoms, although none of them provided this new solution which, so far, is the single one that worked in my setup. Be sure to check them first.

This workaround was applied to the latest Windows update to version 1511 (build 10586), as the update itself did not fix anything in my setup.

The workaround is simple, just fire up the Indexing options and add the following directory to the indexed locations: C:\Users\YOUR_USER\AppData\Local\Packages\windows.immersivecontrolpanel_cw5n1h2txyewy\LocalState.

If your issue is somehow caused by the immersive control panel (also why control panel items might be missing from search), then hopefully this will work. Meanwhile, you might have difficulty finding the Indexing options because of this exact problem, so you can just call it directly by inserting rundll32.exe shell32.dll,Control_RunDLL srchadmin.dll on the Run dialog (WINKEY+R).

Related

Nov 16, 2015 - OnePlus 2 (ARMv8) Encryption Performance Benchmarks

Comments

One of the few things that my next smartphone would have to have was some kind of accelerated filesystem encryption, either hardware or software-based. The reason behind this is to have both the security advantages of full disk encryption [1] and I/O performance along with power efficiency we've come to expect from the latest handsets/tablets.

It was not clear to me whether the new OnePlus 2 would be able to meet these requirements, as I could only find some non-conclusive discussions around encryption ([2] and [3]), even though it seemed to be lacking hardware-based encryption as in [4]. What I knew, however, was that the new Snapdragon 808 and 810 SoCs have extended ARMv8 instructions that improve on-the-fly AES encryption/decryption performance ([5] and [6]), so I took the risk and went for the OnePlus 2.

Last month, when I got it, I immediately made some benchmarking before and after encryption. I am finally sharing with you the results of these benchmarks so you can have peace of mind. The tests/results being made/measured are the following:

  • AnTuTu 64 relevant scores;
  • Androbench I/O performance data;
  • Boot time.

The actual phone used was the OnePlus 2 A2003 64GB, with stock OxygenOS 2.1.1 unrooted and untouched, and a total of 17 installed apps (plus 140 system apps). Battery was always between 70% and 85% as I would recharge it to keep it in range. Environment temperature was between 15 and 17 degrees Celcius. I have waited between 30 to 60 minutes between each test, making sure the device had time to reach a stable temperature and prevent premature CPU/GPU throttling for each next test. Moreover, each test was made after a fresh boot to reduce RAM fragmentation, app caching, etc., providing a clean and similar environment across all test instances. Finally, airplane mode was kept enabled.


AnTuTu 64 relevant scores

The AnTuTu (64-bit) app version used was 5.7.1 and the tests were carried with horizontal orientation. In the screenshots presented at the bottom of the page, the "non-verified score" warning can be safely ignored as it was a consequence of having airplane mode enabled, preventing AnTuTu from checking the phone's model authenticity.

Unencrypted Encrypted Difference
Global 61419 62363 +1.5%
Storage I/O 2559 2555 -0.1%
Database I/O 630 620 -1.6%

Androbench I/O performance data

Unencrypted Encrypted Difference
Sequential Read 231.32 MB/s 232.11 MB/s +0.3%
Sequential Write 124.66 MB/s 122.4 MB/s -1.8%
Random Read 5369.62 IOPS 5208.13 IOPS -3.0%
Random Write 3631.0 IOPS 3268.39 IOPS -10.0%
SQLite Insert 616.86 TPS 510.21 TPS -18.0%
SQLite Update 285.55 TPS 276.15 TPS -3.3%
SQLite Delete 299.5 TPS 269.97 TPS -9.9%
Macro Browser 125.0 ms 186.75 ms +49.4%
Macro Market 140.5 ms 133.25 ms -5.2%
Macro Camera 87.0 ms 103.0 ms +18.4%
Macro Camcorder 166.0 ms 202.5 ms +22.0%

Boot time

The boot time was measured as the time elapsed from the moment the finger pressed the power button until the moment the boot screen faded into the launcher. For the encrypted scenario, the boot time is the sum of the time elapsed from the moment the finger pressed the power button until the phone asked for the encryption PIN, plus the time since confirming the PIN until the moment the boot screen faded into the launcher. I also provide the duration of each of the 2 boot phases in the encrypted scenario. The margin of (human) error for the boot time is probably around half a second.

Unencrypted Encrypted Difference
Boot time 33.5 sec 63.5 sec +89.6%

For the encrypted scenario, the phone took 29.0 seconds to reach the PIN dialog and another 34.5 seconds to reach the launcher, after confirming the PIN.


Conclusions

The OnePlus 2 does not have hardware-based encryption as in [4] but rather software-based encryption as in [5]. There is no noticeable performance drop observed visually. Considering the results, the performance drop is there but is relatively low, insignificant or inexistent depending on the use case, unlike with Android 5.0 in the Nexus 6 [7]. The most impacted use cases were database (SQLite) insert operations at 18.0% performance drop, the browser macro test taking 49.4% longer to finish, and the camera/camcorder macro tests taking 18.4%/22% longer to finish, respectively. All other tests had a performance penalty below 10%, with some really unchanged. It should be noted that I didn't not iterate the tests more than once, meaning that some results might have been affected negatively, which also justifies why sequential read is faster when encrypted. Boot time clearly takes long and requires us to input the PIN in the middle of the process, every time. Finally, let me note that these results should be more or less equivalent in other Snapdragon 810 based devices, like the Nexus 6P, and should also be similar in other ARMv8 devices, assuming they are running Android 5.1 as well. Because you like seeing actual screenshots, here they go:

References
